Quick Details

  • Condition: New
  • Type: Hammer Crusher, Crusher
  • Application: Mining, Ore
  • Motor Type: AC Motor
  • Power(W): 30kw
  • Capacity(t/h): 15-50tph
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: TYM Heavy Mining Machinery
  • Model Number: PC400*600
  • Dimension(L*W*H): 1700x1732x1653mm
  • Weight: 2-60tons
  • Certification: ISO9001:2008
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • max feed size(mm): 250
  • discharge size (mm): 30
  • capacity (t/h): 15-30
  • weight(t): 1.5
  • certificate: ISO9001:2000

Packaging & Delivery

Packaging Details 1. Hammer Crusher/stationary crusher is wrapped by plastic cloth.
2. Motor Power, Motor Wheel, Motor Track, Foundation Bolt, Nut, Plain Cushion, Spring Washer,Triangular Belt etc will be put together in an iron box.
Delivery Time Shipped in 15 days after payment
Product Description



Glass bottle crushed machine, glass recycled machine, glass hammer crusher for sale



Working Principle of PC Glass bottle crushed machine, glass recycled machine, glass hammer crusher for sale



The bulk materials are crushed to the desired size by jaw crusher. Then the materials will be sent to the storage hopper by the elevator. After vibrating feeder, materials will be even quantitatively and continuously into the indoor host crushing. After crushing, the powder is away by fan airflow, the powder selecting machine will grade the powder. Accord with the fineness of fly will be into the large cyclone collector with the gas flow through the pipe to be isolated and collected, and then the powder will be discharged from the powder tube discharge. The airflow returns air duct fan from large cyclone collector inhalation top. In the crushing chamber internal crushing material with certain water content, the crushing heat generated in crushing chamber gas vaporizing expansion changes the gas flow rate, and the various machine pipe joint seal is not strict, let the outside gas is inhaled, the circulating air volume increase, therefore to achieve balance through adjustment of air exhaust fan and host the pipe, and the excess gas into the bag filter, the residual gas into the powder collected, the residual gas is discharged after purification.



PC Glass bottle crushed machine, glass recycled machine, glass hammer crusher for sale Overview:



Hammer crusher is one kind of crusher and widely used in mining, chemical, coal gangue, construction, sand, refractory material, ceramic and other industrial enterprises for materials crushing. It is mainly suitable for crushing the hardness not higher than 320MPa (MPa) materials,such as coal, salt, chalk, gypsum, blocks, limestone, marble,concrete,glass bottle recycling and so on.



The function of PC Glass bottle crushed machine, glass recycled machine, glass hammer crusher for sale



The series of products have the features of small volume ,light weight ,simple structure ,easy operation andmaintenance ,high  ratio of crushing  ,too little crush , even product  size ,high producing capacity .They aresuitable for crushing all the materials of brittle,medium hard ,and compressive strength 150 Mpa.Thefeatures include great hammerhead work ,adoption of new technology casting ,with wear and impact resistance.

This solve the problems of crushing plant dust pollution and gray body leakage.



Technical parameter of PC Glass bottle crushed machine, glass recycled machine, glass hammer crusher for sale



Name

Model

Max  feed

 size (mm)

Handling

capacity (t/h)

Power of

 motor (Kw)

Weight (t)

hammer crusher

PC400×300

200

8--15

11

0.8

PC500×350

210

12--20

18.5

1.2

PC600×400

250

15--30

22

1.5

PC800×1600

300

20--50

55

2.6

PC1000×800

400

30--65

90

6


Notice: Any change of stationary crusher/Hammer Crusher's technical data shall not be advised additionally.

Our Services

Why Choose Us

1. We are Factory ( NOT Dealer )

All machineries from Zhengzhou General Mining Machinery Co.,Ltd are made by ourselves, with lower price, good quality and assured full after service.
So please buy machine from factory.

2. Training & Service

1)Pre-sale services: enthusiasm
We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.



2)Sale services: servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.



3)After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.



4)In addition, we provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

3. If you are new for this business, we will help you

Many thanks for your trust; we can provide you with design scheme for complete production lines, spot inspection and operator training according to your demands and the conditions of applied spot, we can help you choose the right equipments.

4. We’d like to recommend a suitable type for you and send you a best quotation.
