Quick Details

  • Condition: New
  • Type: Raymond Mill
  • Motor Type: AC Motor
  • Power(W): 15-132KW
  • Capacity(t/h): 0.5-30
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: TYM
  • Model Number: YGM7826 YGM3220
  • Dimension(L*W*H): IN DETAIL
  • Weight: IN DETAIL
  • Certification: ISO CE SGS
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: micron fine grinding mill
  • color: as request
  • warranty: 1 year
  • Application: Ore,stone,rock,limestone,coal,etc
  • installation: under engineer guidance
  • parts: supply
  • training: engineer will train your worker for free
  • Sale services: Installment,technical support,repair,wear parts
  • Grinder size: standard
  • factory visit: warmly welcome

Packaging & Delivery

Delivery Time Shipped in 10 days after payment
Product Description

New style YGM Series High Pressure Ultrafine Grinding mill Performance

1. Application of Grinding Mill:

Grinding mill is used for grinding the material below scale 6 of mohs hardness and 250-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industrial, chemical engineering and building material for high fine powder generation and processing, such as talcum, barite, marble, limestone, charcoal blacks.

2. Features of Grinding Mill:

   <1. Wide application scope,can use to crush materials less than 6 moth of hardness.



   <2. Under the effect of high pressure spring, the fineness of final product is increased greatly.



   <3. Compared with Jet Milling, the energy consumption is lower.



   <4. Less investment, high efficiency, recycling fast



   <5. Independent system, less Production links, materials less than 25mm can be put into processing directly.



   <6. No pollution, dedusting effect is completely meet national standards.



   <7. The sealing effect of grinding roller device is good.

3. Working Principle of Grinding Mill:

High pressure grinding mill hosts 1000-1500kg high-pressure spring fastening on roller suspender.After working,grinding roller rotates around spindle and rolling close to the grinding ring under the high pressure spring and centrifugal force.Its rolling pressure is 1.2times of Raymond powder machine under the same conditions,so the output is much improved.When the material is put into the grinding chamber,it was grinded between grinding roller and grinding ring,the powder was brought into analytical machine by recirculation air from air blower,qualified powder was flowed into the cyclone powder collector,the large particles was going to be regrind.Circulating air return to blower to repeat the above process and the left air entered the wind bag filter for purification.When the grinding roller and grinding ring reached a certain wear and tear,which could ensure a suitable yield and fineness under the steady pressure by adjusting the length of high-pressure spring.

4. Technical Data of Grinding Mill:



Model

YGM7826

YGM8327

YGM9531

YGM3220

Number of rolls(pcs)

3

3

4

3

4

Diameter of rollers(mm)

Ø260

Ø270

Ø310

Ø320

Ø320

Internal diameter of ring(mm)

Ø780

Ø830

Ø950

Ø970

Ø970

Rotational speed of main unit(r/min)

160

140

130

148

130

Max feeding size(mm)

20

20

25

20-25

20-25

Capacity(kg/h)

25-500

30-680

150-1000

2000-5800

3000-6000

Motor of the main unit(power)

Y225M-8-18.5

Y225M-8-22

Y225S-4-37

Y225S-4-45

Motor of the blower(power)

Y160L-4-15

Y180M-4-18.5

Y200L-4-30

Y200L-4-37

Motor of the classifier(power)

Y160M-6-7.5

Y160M-6-7.5

Y160M-6-7.5

YCT200-4A-11

Total power(kw)

41

48

74.5

93

Overall dimension(m)

4.5×4.2×5.1

5.3×4.1×5.2

7.1X5.9X7.9

7.1 X 5.9 X 7.9

Weight(T)

4.8

6

11.5

13.2

Diameter of final particle(mesh)

500 mesh to 1250 mesh, the finest can reach 2500 mesh




Company Information

ABOUT US

Zhengzhou General Mining Machinery Co., Ltd was founded in 2004, is a set design, production and after-sale service in one professional unit.Over the past years, with a strong technical force, advanced production technology, sophisticated processing equipment, complete testing means, high-quality product performance, first-class after-sales service

Contact Us

If you are interested in our products,just feel free to contact with me:
Zhengzhou General Mining Machinery Co.,Ltd.
Contact with Ms. Cherry
Skype: cherry-niu0728
Tel: 86-371-67971297
Mob: 86-13633718025

Related Products

In order to give you more professional response,please kindly tell me following information:


  1. What's your raw material to be processed?

  2. What capacity do you want?

  3. What final product size you require?
